Specifications
Reference specification table. Final configuration may vary with options and scope.
| Parameter | Value |
|---|
| Machine Model |
LU-TB550V |
| Voltage |
220V 50-60HZ 570W |
| Suitable Bottle Size |
φ50-110mm25-130mm(H) (Can be customized) |
| Labeling Speed |
25-45 bottles/min |
| Labeling Accuracy |
±1mm |
| Suitable Label Size |
20mm-130mm(W)20mm-290mm(H) |
| Label Roll OD |
About φ280mm |
| Label Roll ID |
About φ76mm |
| Air Pressure |
0.4-0.6MPa |
| Machine Size |
About 2800 1200 1400mm |
| Machine Weight |
About 200kg |
CAD / dimensions
CAD/dimensions are provided in a pop‑out viewer.
No CAD/dimensions drawing uploaded yet.
Site requirements
- Voltage: 220V 50-60HZ 570W
- Air pressure: 0.4-0.6MPa
- Footprint / size: φ50-110mm25-130mm(H) (Can be customized)
For the most accurate proposal, include: product viscosity/foaming, container size, closure type, and required units per hour.
Quick answers
Key answers buyers and engineers often need before shortlisting this machine.
What is Automatic Polygon Bottle Labeling Machine used for?
This is an automatic labeling machine. It is designed for accurate and efficient labeling of various polygon products, including bottles, cans, and containers
What output can Automatic Polygon Bottle Labeling Machine achieve?
This page lists output at 25-45 bottles/min. Actual throughput depends on the product, pack format, changeover requirements and the overall line setup.
What utilities or site requirements should I plan for?
Voltage: 220V 50-60HZ 570W; Air pressure: 0.4-0.6MPa; Machine size: About 2800 1200 1400mm; Footprint / size: φ50-110mm25-130mm(H) (Can be customized)
Can Lancing UK help match this machine to my product and container?
Yes. Lancing UK can review your product, container or pack style, target output and site constraints to confirm whether this machine is the right fit before supply.
Talk to a specialist
We’ll confirm suitability, options, integration, and realistic throughput for your product.
Project planning notes
Labelling performance depends heavily on container presentation, spacing, label format and the visual standard expected from the finished pack. That means the most useful shortlist usually considers upstream handling, changeovers and coder integration as part of the same conversation.
- Confirm the pack shape, label position and the visual tolerance that matters commercially.
- Check how packs arrive to the labeller and whether spacing or orientation needs support.
- Plan for label changes, SKUs and any print or code requirement at the same stage.
Budget, timing and quote planning
Useful commercial checks before you shortlist or request a final quotation.
Shortlisting automatic polygon bottle labeling machine is usually about more than the base machine price. Buyers normally need to confirm container presentation, label format, coder needs and changeover range, then check how that scope fits the wider line, labour model and growth plan.
This page currently highlights throughput as 25-45 bottles/min and utilities as 220V 50-60HZ 570W. If your real pack, product or site conditions differ, the final budget and lead time can change, so it helps to validate those assumptions early.
- Confirm the exact product and pack format the quote is based on.
- Check output assumptions, changeover expectations and operator involvement.
- List any utilities, footprint, guarding or line-interface constraints on site.
- Confirm whether FAT, delivery, commissioning, training or spares support are included.
