Key information to help you specify the right configuration.
Auto‑scrolling. Hover to pause.
Reference specification table. Final configuration may vary with options and scope.
| Parameter | Value |
|---|---|
| Machine model | LU-YT4TZ |
| Machine power | 110/220V, 800W |
| Air pressure | 0.5–0.8MPa |
| Filling range | 100–1000ml (5–100ml / 10–300ml / 50–500ml / 500–3000ml / 1000–5000ml can be chosen) |
| Filling accuracy | About ±3g |
| Filling speed | 20–50 bottles/min |
| Conveyor belt size | 1980×100mm |
| Machine size (L×W×H) | About 1025×900×1700mm |
| Machine weight | About 259kg |
| Package size (L×W×H) | About 2060×960×1880mm |
| Package weight | About 360kg |
CAD/dimensions are provided in a pop‑out viewer.
No CAD/dimensions drawing uploaded yet.
Key answers buyers and engineers often need before shortlisting this machine.
Application This machine is suitable for filling liquid, such as shampoo, laundry detergent, cooking oil, etc. It can work with automatic labeling machine and capping machine, realizing automated production
This page lists output at 20–50 bottles/min. Actual throughput depends on the product, pack format, changeover requirements and the overall line setup.
Power: 110/220V, 800W; Air pressure: 0.5–0.8MPa; Machine size: About 1025×900×1700mm; Footprint / size: 1980×100mm
Yes. Lancing UK can review your product, container or pack style, target output and site constraints to confirm whether this machine is the right fit before supply.
We’ll confirm suitability, options, integration, and realistic throughput for your product.
This machine is normally shortlisted around product behaviour, dose accuracy, fill speed and how the pack will be presented to the next stage of the line. A stronger shortlist usually considers the filler in the context of the container, the closure and the output target rather than as a standalone spec sheet.
Useful commercial checks before you shortlist or request a final quotation.
Shortlisting lu-yt4tz automatic 4 nozzles piston liquid filling machine is usually about more than the base machine price. Buyers normally need to confirm product behaviour, fill volume, dosing method and changeover requirements, then check how that scope fits the wider line, labour model and growth plan.
This page currently highlights throughput as 20–50 bottles/min and utilities as 110/220V, 800W. If your real pack, product or site conditions differ, the final budget and lead time can change, so it helps to validate those assumptions early.
Send a message and we’ll respond with configuration options, pricing guidance and lead times.
