Specifications
Reference specification table. Final configuration may vary with options and scope.
| Parameter | Value |
|---|
| Model |
LU-YT4T-4PX |
| Voltage |
110/220V 50-60HZ 1KW |
| Filling Range |
10-180ml / 30-500ml / 100-1000ml |
| Working Speed |
About 30-50 bottles/min |
| Filling Pump |
Piston pump |
| Filling Accuracy |
≤ ±1% |
| Filling Head |
4 (Customizable) Inner dia.: 6mm 4 & 8mm 4 |
| Control |
7-inch touch screen |
| Storage Tank |
90L |
| Conveyor |
2000 × 114mm (Customizable) |
| Air Supply |
0.6-0.8MPa (Air compressor required, sold separately) |
| Size |
2000 × 800 × 1800mm |
| Weight |
200kg |
| Packaging Size |
2070 × 960 × 2010mm (100-1000ml) |
| Packaging Weight |
392kg (100-1000ml) |
CAD / dimensions
CAD/dimensions are provided in a pop‑out viewer.
No CAD/dimensions drawing uploaded yet.
Site requirements
- Voltage: 110/220V 50-60HZ 1KW
- Footprint / size: 2000 × 800 × 1800mm
For the most accurate proposal, include: product viscosity/foaming, container size, closure type, and required units per hour.
Quick answers
Key answers buyers and engineers often need before shortlisting this machine.
What is LU-YT4T-4PX Automatic Paste Lotion Bottle Filling Machine used for?
This automatic piston pump filling machine is equipped with feeding pump,this is more convenient for feeding filling material.Filling work is controlled by servo motor, this is can simplify machine operation and improves working efficiency. Different filling range can be chosen and multiple filling nozzle can be customized according to operation need.This machine is suitable for filling hot sauce, cosmetic cream,lotion etc
What output can LU-YT4T-4PX Automatic Paste Lotion Bottle Filling Machine achieve?
This page lists output at About 30-50 bottles/min. Actual throughput depends on the product, pack format, changeover requirements and the overall line setup.
What utilities or site requirements should I plan for?
Voltage: 110/220V 50-60HZ 1KW; Footprint / size: 2000 × 800 × 1800mm
Can Lancing UK help match this machine to my product and container?
Yes. Lancing UK can review your product, container or pack style, target output and site constraints to confirm whether this machine is the right fit before supply.
Talk to a specialist
We’ll confirm suitability, options, integration, and realistic throughput for your product.
Project planning notes
This machine is normally shortlisted around product behaviour, dose accuracy, fill speed and how the pack will be presented to the next stage of the line. A stronger shortlist usually considers the filler in the context of the container, the closure and the output target rather than as a standalone spec sheet.
- Confirm how the product behaves during filling, cut-off and changeover.
- Check whether the container presentation into the filler is stable enough for the required output.
- Plan how filling performance will affect the capping, sealing or labelling stage that follows.
Budget, timing and quote planning
Useful commercial checks before you shortlist or request a final quotation.
Shortlisting lu-yt4t-4px automatic paste lotion bottle filling machine is usually about more than the base machine price. Buyers normally need to confirm product behaviour, fill volume, dosing method and changeover requirements, then check how that scope fits the wider line, labour model and growth plan.
This page currently highlights throughput as About 30-50 bottles/min and utilities as 110/220V 50-60HZ 1KW. If your real pack, product or site conditions differ, the final budget and lead time can change, so it helps to validate those assumptions early.
- Confirm the exact product and pack format the quote is based on.
- Check output assumptions, changeover expectations and operator involvement.
- List any utilities, footprint, guarding or line-interface constraints on site.
- Confirm whether FAT, delivery, commissioning, training or spares support are included.
