Key information to help you specify the right configuration.
Auto‑scrolling. Hover to pause.
Reference specification table. Final configuration may vary with options and scope.
| Parameter | Value |
|---|---|
| Model | LU-GY1C |
| Power Supply | 220V / 110V, 50/60Hz |
| Power | 130 W |
| Filling Accuracy | ≤ ±0.5% |
| Filling Speed | 10–20 bottles/min |
| Filling Volume Range | 5–100 ml / 10–300 ml / 50–500 ml / 100–1000 ml / 500–3000 ml / 1000–5000 ml (optional) |
| Conveyor Size (L×W) | 2000 × 100 mm |
| Filling Nozzle Diameter | Φ10 mm |
| Required Air Pressure | 0.4–0.6 MPa |
| Air Connector Size | OD 8 mm |
| Air Consumption | ≥ 0.1 m³/min |
| Machine Weight | 24 kg (filling machine) + 4 kg (hopper) + 61 kg (conveyor) |
| Packing Weight | 30 kg (filling machine) + 5.5 kg (hopper) + 89 kg (conveyor) |
| Packing Size | 113 × 35 × 30.5 cm (filling machine) / 46.5 × 47 × 52 cm (hopper) / 210 × 62 × 53 cm (conveyor) |
CAD/dimensions are provided in a pop‑out viewer.
No CAD/dimensions drawing uploaded yet.
Key answers buyers and engineers often need before shortlisting this machine.
The LU-GY1C filling machine is designed for efficient, semi-automatic filling of liquids and pastes such as water, lotion, honey, and cream. Equipped with a 2-meter conveyor belt, it integrates seamlessly with automatic capping and labeling machines, making it ideal for streamlined production lines in cosmetics, food, pharmaceuticals, and daily chemical industries
This page lists output at 10–20 bottles/min. Actual throughput depends on the product, pack format, changeover requirements and the overall line setup.
Voltage: 220V / 110V, 50/60Hz; Power: 130 W; Air pressure: 0.4–0.6 MPa; Air consumption: ≥ 0.1 m³/min
Yes. Lancing UK can review your product, container or pack style, target output and site constraints to confirm whether this machine is the right fit before supply.
We’ll confirm suitability, options, integration, and realistic throughput for your product.
This machine is normally shortlisted around product behaviour, dose accuracy, fill speed and how the pack will be presented to the next stage of the line. A stronger shortlist usually considers the filler in the context of the container, the closure and the output target rather than as a standalone spec sheet.
Useful commercial checks before you shortlist or request a final quotation.
Shortlisting lu-gy1c pneumatic paste & liquid filling machine is usually about more than the base machine price. Buyers normally need to confirm product behaviour, fill volume, dosing method and changeover requirements, then check how that scope fits the wider line, labour model and growth plan.
This page currently highlights throughput as 10–20 bottles/min and utilities as 220V / 110V, 50/60Hz. If your real pack, product or site conditions differ, the final budget and lead time can change, so it helps to validate those assumptions early.
Send a message and we’ll respond with configuration options, pricing guidance and lead times.
